4 Flute Flat Carbide End Mill Cutter

4 Flute Flat Carbide End Mill Cutter

4 Flute Flat Carbide End Mill Cutter
4 Flute Flat Carbide End Mill Cutter4 Flute Flat Carbide End Mill Cutter4 Flute Flat Carbide End Mill Cutter4 Flute Flat Carbide End Mill Cutter
CategoriesFlat End Mills
BrandMSUTOOLS
ModelD1mm-20mm
MaterialSolid Carbide
Internal CoolingWithout
No of Cutting Flute4 Flute
TypeFlattened
CoatingTiAIN/Altin
Cutting DirectionRight - Hand
Helix Angle35°
Precision±0.01
WorkpieceCarbon Steel/ Alloy Steel/Grey Cast Iron
ApplicationMilling
Cutting Diameter1mm-20mm
Full Length50mm/75mm/100mm/150mm
FOB portAny ports of China
Terms of PaymentMoneyGram, T/T, Paypal
Update Time2021-10-17
Detail Information
4 Flute Carbide End Mill Cutters
Description
4 Flute Carbide End Mill
Hardness
HRC45 (HRC55/60/65 Available)
Coating
ALTIN/TIALSIN
Helix Angle
35°
Workpiece
Carbon Steel/ Alloy Steel/Grey Cast Iron/ Nodular Cast Iron
Application
Side Face/ Step Shoulder/ Straight Slot /Deep Slot

Features
1.  Premium carbide grade for making carbide endmill cutters.
2. Cutting edge over center, easy chip removal, no sticky cutter.
3. ALTIN Coating, super wear resistance and heat resistance.
4. Chamfer Shank, easy operation.

All End Mills are made by 5 Axis CNC machines such as ANCA/Walter, the end mills come to be high precision, long working life, high efficiency.

1. All standard types of end mills and drills have stock, can be fast delivery( 3-7 days).
2. Free samples for test, 4mm and 6mm, each 2 pieces.
3. We can produce special types of end mills and drills per customer's drawing and samples.

If you are interested in our products, please send us inquiry by info@msutools.com, we will send full catalogue and pricelist.
